Forum Topic

Show Me Your Intel Rig(Two images per post, over 640x480pixels will be deleted)

  • MUGEN Power!!! :D

    Specs:
    Intel Core i7 3930k (6cores 12threads)
    EVGA X79 Dark (2011)
    G.Skill TridentX 2400mhz x 8 (64gb)
    EVGA GTX 680 TRI SLI
    CoolerMaster Cosmos 2(fully modded)
    Enermax Maxrevo 1500w
    Corsair Force GT 120gb x2 raid 0
    WD Caviar black 2tb

    External Image

    External Image
  • MUGEN Power!!! :D


    belated merry christmas papi. bibitaw na yan ah. :D

    nakasabay kita sa coastal a few weeks ago dala mo si vs-xx. :)

    intel core 2 duo pc. :D

    External Image
  • External Image


    Project : Mini
    Codename: D3vil Frostbyte

    Processor: Intel Core i5 2500k
    Motherboard: Gigabyte Z77N-Wifi ITX
    RAM: Corsair Vengeance Pro 1866 8GB(4gbx2)
    GPU: Asus R9 280X DCU II Top
    PSU: Silverstone 600W Full Modullar
    SSD: Kingston SSD Now V300
    HDD: WD 500GB Blue
    HDD: WD 1TB Blue
    Cooler: Cooler Master Seidon 120M
    Fans: Cougar Dual-X Red x2
    Case: Cooler Master Elite 130

    Share lang mga ser :)
  • @aceorpilla

    Nice card.
  • @aceorpilla

    Nice card.


    Thanks boss :)
  • @aceorpilla - nice asesnsado na
  • sir, post more pix! interesado ako sa cm elite 130.
    bubuo rin kasi ako ng devil using 130 :)
  • @aceorpilla - nice asesnsado na


    minsan lang mag upgrade , tapos Video card lang, tapos back to air cooling na hahaha pero grabe from around 20-30KGS ngaun 7KGS nalang sya hahah yey

    sir, post more pix! interesado ako sa cm elite 130.
    bubuo rin kasi ako ng devil using 130 :)


    sige bro, pag uwi ko galing work post ako ng pics, medjo Crampped since ginamit ko is regular PSU, pero full Modullar

    ung fans imba, kahit crampped imba ung airflow sa loob dahil sa fans haha

    for temps naman

    Using Aida64 as Software sensor

    CPU - idle 27, kinda confusing kasi pag check mo sya per core is around 34-38, Load around 54 (Seidon 120M+ Sandwich by Cougar Dual X fans 120mm)
    GPU idle - 36, Load AC4 and COH on Ultra - 65-68 Open Case 70 Closed Case (Optimize by MSI afterburner ung Fans speed depending on the temp of the GPU kasi parang walang kwenta ung sa AMD catalyst hindi nag aauto -_-)
  • pa-post lang... walang pa rin nabago bukod sa paubos na HDD space..
    External Image

    External Image

    Intel Core i7 3770K
    Gigabyte GA-Z77X-UP7
    Corsair Dominator GT DDR3 1866MHz 16GB (2x8GB-Kit)
    MSI R6990-4PD4GD5 (Main)
    Palit GTS250 Green (Physx)
    Creative Sound Blaster X-fi Fatal1ty Titanium
    2 x Corsair Force GS 128GB (RAID0 - System)
    4 x 3TB Seagate Barracuda ST3000DM001 (RAID5 - Data)
    4 x 3TB Seagate Barracuda ST3000DM001 (Data)
    Bitfenix Superspeed USB 3.0 Card Reader
    Zalman MFC2
    Zalman ZM-MH200 U3
    Corsair AX1200
    Coolermaster Cosmos S


    -- edited by vanguard on Jan 15 2014, 02:07 PM
  • @vanguard
    mukhang bago pa din yan sir =)

    eto luma ^_^
    External Image

    External Image

    i7 3770k, ASUS MaximusVgene, Corsair Dominator platinum 16gb 1866
    ZOTAC GTX 480 AMP, H80i cooler, HX850w, PS07 case, Lachesis, G15 v2
    120gb Corsair ForceGT SSD(OS), 80GB velociraptor(games), 500GB, 1.5tera
    Samsung 32EH5300, Z-5500 THX, UPS-APC RS1000VA
  • @rassengan

    ito sya before Cable management

    <click here for link>

    <click here for link>

    tapos ito na sya nung cable management ko , masikip padin pero halos wala ng cable na nag block ng airflow sa loob kasi naktago na sya sa mga sides or tops

    <click here for link>

    <click here for link>

    <click here for link>

    the other side

    <click here for link>

    <click here for link>

    <click here for link>

    <click here for link>

    i hope those pictures would help you out :)

    muka lang syang magulo sa first look pero nakatago na ugn cables sa mga gilid sa sulok sulok so from the front of the case going into the mobo walang mga cables na nakahrang :)
    ung 24pin pinadaan ko nalang sa top ng hdd kasi sobrang haba hahaha

    -- edited by aceorpilla on Jan 15 2014, 10:46 PM
  • External Image

    External Image


    i7 4770k
    asrock z87 fatal1ty killer
    asus r9 280x dcu ii top
    16gb gskill ripjawx cl9 1866
    640gb wdc blue
    swiftech h220
    fsp everest 700w 80+ bronze
    cm 690ii advance
    lg dvdrw

    papalitan ko case ko obsidian 750d sa malapit na hinaharap mga feb 15. di kasi makapag push pull sa cooler di kasya. pati psu mas mataas na wattage na at dagdag ng gpu ipon ipon mode na.

    -- edited by princedanly on Jan 18 2014, 10:07 AM
  • @patikiw_pilipinas

    yan ang bago chief! nasan na yung cosmos mo?

    External Image

    Intel Core i5 4570
    Gigabyte GA-Z87N-WiFi
    Corsair Vengeance 16GB DD3 1866 CL9
    Sapphire HD 7750
    Intel 335 180GB SSD
    Western Digital 1TB Caviar Blue
    Corsair HX620
    Fractal Node 304
    Intel Core i5 2310
    Gigabyte GA-Z77N-Wifi
    Corsair Vengeance 16GB DDR3 1600 CL9 (2 x 8GB )
    1 x 500GB Seagate Barracuda
    1 x 320GB Seagate Momentus
    2 x 2TB Western Digital Caviar Green
    Intel Dual Port Gigabit Server Adapter
    Noctual NH-L9i
    Silverstone ST45SF-G
    Fractal Node 304
  • share lang eyefinity rig na semi finished ^^:


    External Image


    External Image



    cpu: Intel i5 3570k @ 4.4ghz(di pa naooc to the max la pa oras kakatapos lang kasal hehe)
    cpu cooler: Deepcool Ice Blade Pro V2 (w/ SP120 High Performance pull config)
    mobo: Msi z77 g45 gaming series
    mem: Corsair Vengeance 8Gb (2 x 4Gb) 1600 Mhz
    gpu: 2 x Msi r9 280x Gaming Series (Crossfire)
    hdd: WD 1T Caviar Blue
    psu: Corsair AX860

    nyt nyt tpc!!
  • ^
    Very nice setup!!!
  • bagong dagdag scythe kaze jyuni slim tumatama kasi sa ram kaya slim push, cougar votex pull
    External Image

    External Image


    ipon mode for obsidian 750d nasisikipan nako sa mid tower.
  • Share lang din po mga masters. My Simple gaming rig..

    External Image


    External Image


    Intel I5 4670k
    Asus Gryphon z87 w/ armor kit
    Corsair Dominator platinum w/ lightbar
    Sapphire R9 270x Toxic
    Nzxt kraken x40
    Seasonic x series 750w gold Full modular
    256 GB Samsung 840 Evo
    500GB WD blue
  • External Image


    External Image


    External Image
  • External Image


    External Image


    Intel Core 2 Duo E7400 Oc'd to 3.6Ghz
    Gigabyte G31M-ES2C
    2x2GB RAM
    CM TX3 HSF
    CM Thunder M 520w PSU
    Asus GeForce GTX 650 Ti
    320GB WD HDD
    80GB Samsung IDE HDD
    40GB Samsung IDE HDD
    LG DVD Writer
  • kakainstall lang ng led at may mas matinong cam hehe

    External Image


    External Image
  • eto pa

    External Image


    External Image
  • External Image


    Project : Mini
    Codename: D3vil Frostbyte

    Processor: Intel Core i5 2500k
    Motherboard: Gigabyte Z77N-Wifi ITX
    RAM: Corsair Vengeance Pro 1866 8GB(4gbx2)
    GPU: Asus R9 280X DCU II Top
    PSU: Silverstone 600W Full Modullar
    SSD: Kingston SSD Now V300
    HDD: WD 500GB Blue
    HDD: WD 1TB Blue
    Cooler: Cooler Master Seidon 120M
    Fans: Cougar Dual-X Red x2
    Case: Cooler Master Elite 130

    Update lang po :)
  • i5 4570
    Antec Kuhler 930
    ASUS Z87 - A
    MSI Gaming R9 290
    8GB G.Skill Ripjaws Ram
    256GB Samsung EVO SSD
    1TB WD Blue
    XFX 750w PSU
    4x AF120 2x SP120
    NZXT Mesh Fan Controller

    External Image

    External Image


    -- edited by T4Gx on Mar 15 2014, 02:16 AM
  • External Image
  • my corsair rog 250D...
    External Image


    my corsair rog 900d...
    External Image
  • Processor: Intel Core i5 3570K
    Motherboard: Gigabyte Z77X-UP5 TH
    RAM: Gskill Ripjaws 8GB cl8(4gbx2)
    GPU: Sapphire R9 290 Tri-X + EK FC 290X Nickel Water Block
    Sound Card: Creative X-fi Titanium + Logitech x540
    Keyboard : Razer DeathStalker
    Mouse : Razer Deathadder 2013
    Monitor : Asus VX239h
    PSU: Seasonic x850 gold (fully modular)
    SSD: Corsair Force 3
    HDD: WD 1TB Blue + 80GB Seagate
    Cooler: Swiftech H220 + EK Coolstream XTX 240 Radiator
    Fans: Cougar Dual-X Green x4(120mm) +Cougar Dual-X Black x2(120mm) +Cougar Dual-X Black (140mm) + Noctua NF-F12 x2
    Case: Corsair Carbide 500R

    External Image
  • ang ganda dito sa thread na to kaso metal casing parin uso dito......

    i have my core2quad v8 cooler master fanless with thermaltake tsunami casing purong aluminom lahat
  • Still can't let go of my old style Xeon Skulltrail gaming / chess rig ^^
    StarCraft II, League of Legends, and DOTA 2 lang naman nilalaro ko, and Houdini 4 Pro pala na chess engine.

    Update: upgraded to 16GB DDR2-800 FB-DIMM ECC

    External Image


    2x (8 cores) Intel Xeon E5450 3.0GHz OC'ed to 3.6GHz
    Supermicro X7DWE mobo (LGA 771)
    Micron Technology 16GB (4x4GB) DDR2-800 FB-DIMM ECC CL5
    Palit GTX 650 Ti Boost OC Ed. 2GB GDDR5 192-bit
    2x 60GB SanDisk/Intel SSD
    3x Hitachi 500GB SAS 15,000 rpm (RAID 0)
    Adaptec 2405 SAS RAID controller
    Sound Blaster X-Fi Xtreme Audio
    Cooler Master HAF 932
    Windows 8.1 Pro

    External Image

    <click here for link>
  • External Image



    bagong dagdag shroud
    External Image


    -- edited by princedanly on Jun 22 2014, 03:13 AM
  • My ongoing project

    Devil's Canyon

    External Image
